英格索兰90-250kW螺杆空压机
由 合肥凯旷
英格索兰90-250kW螺杆空压机
品牌：美国英格索兰
压力：7 – 12 Barg
功率：90 – 250 kW
气量：12.3 – 44.6 m3/min
| 机型 | 压力 | 电机功率 | 排气量 | 噪音 | 外形尺寸（mm） | 重量 | ||
| barg | kW | m3/min | dB(A) | 长 | 宽 | 高 | Kg | |
| V90-7 | 7 | 90 | 17.1 | 72±3 | 3171 | 1574 | 1903 | 2703/2510 |
| V90-8 | 8 | 90 | 15.6 | 72±3 | 3171 | 1574 | 1903 | 2703/2510 |
| V90-10 | 10 | 90 | 14.0 | 72±3 | 3171 | 1574 | 1903 | 2703/2510 |
| V90-12 | 12 | 90 | 12.3 | 72±3 | 3171 | 1574 | 1903 | 2703/2510 |
| V110-7 | 7 | 110 | 20.5 | 72±3 | 3171 | 1574 | 1903 | 2833/2640 |
| V110-8 | 8 | 110 | 19.6 | 72±3 | 3171 | 1574 | 1903 | 2833/2640 |
| V110-10 | 10 | 110 | 17.5 | 72±3 | 3171 | 1574 | 1903 | 2833/2640 |
| V110-12 | 12 | 110 | 15.4 | 72±3 | 3171 | 1574 | 1903 | 2833/2640 |
| V132-7 | 7 | 132 | 24.1 | 72±3 | 3171 | 1574 | 1903 | 3160/2945 |
| V132-8 | 8 | 132 | 22.8 | 72±3 | 3171 | 1574 | 1903 | 3160/2945 |
| V132-10 | 10 | 132 | 21.0 | 72±3 | 3171 | 1574 | 1903 | 3160/2945 |
| V132-12 | 12 | 132 | 18.5 | 72±3 | 3171 | 1574 | 1903 | 3160/2945 |
| V160-7 V160-8 | 7 8 | 160 160 | 29.2 27.6 | 72±3 72±3 | 3171 3171 | 1574 1574 | 1903 1903 | 3160/2945 3160/2945 |
| V160-10 | 10 | 160 | 25.0 | 72±3 | 3171 | 1574 | 1903 | 3160/2945 |
| V160-12 | 12 | 160 | 22.0 | 72±3 | 3171 | 1574 | 1903 | 3160/2945 |
| V250-7 | 7 | 250 | 44.6 | 4000 | 1930 | 2175 | 4800/4900 | |
| V250-8 | 8 | 250 | 43.0 | 4000 | 1930 | 2175 | 4800/4900 | |
| V250-10 | 10 | 250 | 38.8 | 4000 | 1930 | 2175 | 4800/4900 | |
